3M Scotch Super 33 Vinyl Electrical Tape for Electrical Insulation & UV Rays Resistance
3M 33+ Vinyl Electrical tape is a PVC backing with 3M pressure-sensitive and rubber-resin adhesive, which provides electrical and mechanical protection. And its excellent strength and flexibility means it can stretch and recover up to 250% without breaking. It is a 0.178 mm thickness, premiun grade tape that provides electrical insulation for all wires and cables with rated voltage up to 600V. It is characterized by flame-retardant and corrosion of electrical conductors and can withstand temperatures ranging from 0 to 221°F(-18 to 105°C). Suitable for solid dielectric cable insulation, synthetic cable insulation, sheath and splicing compounds.
-
3M Scotch 23 EPDM Rubber Splicing Tape for Insulating & Sealing
3M Scotch 23 Rubber Splicing Tape is a black, 30-mil (0.76 mm) thick, premium grade, highly conformable, rubber splicing tape composed of a self-fusing Ethylene Propylene Diene Monomer (EPDM) rubber backing supplied on a removable polyethylene liner. It withstands temperatures up to 194 °F (90 °C) with an emergency overload rating to 266 °F (130 °C).
Choose Scotch Rubber Splicing Tape 3M 23 generally called electrical tape, especially designed for insulating, splicing, and padding low- to high-voltage cables, especially in outdoor or underground applications. Adding rubber tapes to your toolbox can help reinforce your work for years of worry-free and maintenance-free service.
-
3M 220 Safety-Walk Water-resistant Fine Resilient Tape for Barefoot-traffic Areas
3M Safety-Walk Slip Resistant Fine Resilient Tape 200 Series is a fine-resilient textured, slip-resistant vinyl surface with a pressure-sensitive adhesive backing. It provides enhanced safety and comfort in wet barefoot traffic areas.
3M Safety-Walk Slip Resistant Fine Resilient Tape 220 has fine textured, light duty anti-slip surface with a pressure-sensitive adhesive backing provides enhanced safety. The adhesive backing makes installation as easy as press-in-place. This high performance, water-resistant adhesive is ideal for wet conditions. As well it’s quite suitable for barefoot-traffic areas.
-
High Peel and Shear Strength 3M DP460 DP420 DP190 Epoxy Adhesive for Aerospace Applications
3M DP460 is a two-part epoxy adhesive with a 2:1 mix ratio. It has a working life of 60 minutes and handling strength in approximately four hours. Its high peel and shear strength characteristics provide the product a strong, durable bond to many surfaces. 3M DP460 has very good performance for enhanced impact resistance and high fatigue resistance to withstand harsh conditions. 3M DP190 is gray adhesive and features an extended work life for adjustment and precise application, reaching handling strength in 10 hours. It is engineered for a 1:1 mix ratio and exhibits good environmental aging properties, delivering long-term durability. 3M DP420 is a toughened, two-part epoxy structural adhesive that provides good strength along with high impact and fatigue resistance to meet demanding bonding challenges. 3MDP420, DP460, DP190 can replace mechanical fasteners, screws, rivets and spot welds in many applications, and bond to many surfaces, such as bonds metals, ceramics, glass, many composites and plastics.
-
3M Acrylic Plus Tape PT1100 PT1000 PT1500 for Automotive Exterior Attachment
The 3M PT1000 Acrylic Foam Tape Series are made from a black acrylic foam then coated with formulated acrylic adhesives for high adhesive build rates, particularly suitable for attaching automotive components. It features two adhesives, and non liner side adhesive desigin with special properties produce a high adhesion on some tough surfaces.
• 3M Acrylic Foam Adhesive Tapes can compensate stress due to their unique viscoelasticity. In contrast to foam adhesive tapes (PE, PU adhesive tapes), they can cope with significant elongation differences between substrates in case of temperature changes.
• Easy to use: The tape can be easily processed in multiple ways to cut and to apply.
• Immediate initial adhesion: The initial adhesion allows immediate further processing without temporary support or fixtures.
• Freedom of design: enables the easy differentiation of vehicle models through modified trim attachments without change of the body configuration.
• Sealing and damping properties: positive improvement of NVH properties.
-
3M 55280 Double Coated Adhesive Tape With Thick PVC Film for Automotive Rearview Mirror
3M 55280 is double coated tape with a thick PVC film improved handling with ease of die cutting and laminating. The high tack adhesive provides relatively high initial adhesion and good shear holding power to a variety of surfaces, at the same time, it has good vibrating resistance ability. It’s widely used for plastic film lamination, bonding,splicing, mirror attachment etc. It can be pasted on various surfaces withstand heavy loading, and teared off without leaving residue. It is always for household or automotive usage. With log roll size of 1220mm*50m. Custom roll size and die cut size are both available.
-
3M 9703 Electrically Conductive Adhesive Transfer Tape for LCD PCB Screens interconnection
3M 9703 electrically Conductive Adhesive Transfer Tape (ECATT) is a pressure sensitive adhesive (PSA) transfer tape with anisotropic electrical conductivity.
It’s part of a family of anisotropic (Z-Axis) conductive tapes and thermoset films. For applications where mechanical clamping is not desired, or where improved electrical, thermal and mechanical performance is required, these alternative products should be considered.
The PSA matrix is filled with conductive particles which allow interconnection between substrates through the adhesive thickness (the “Z-axis”) but are spaced far enough apart for the product to be electrically insulating in the plane of the adhesive.
The PSA tack properties and lack of any thermal curing make 3M ECATT 9703 easy to use in assembly operations. 3M ECATT 9703 electrically connects and mechanically bonds medium pitch flexible circuits with other flexible circuits (flex), rigid printed circuit boards (PCB) or LCD screens. 3M ECATT 9703 is electrically conductive and offers good adhesion to common PCB substrates such as copper, gold, FR-4 epoxy, DuPont polyimide and polyester films, can also be applied as die cut parts or in roll form and has good adhesion to common EMI/RFI substrates such as aluminum, stainless steel, and smooth gasket materials.
Stable electrical performance in any flexible circuit interconnection application may require mechanical reinforcement (clamping).
3M ECATT 9703 also electrically connects and mechanically bonds EMI/RFI shield and gaskets to metal frames and enclosures. The low contact resistance and tape construction result in good EMI performance.
-
Double Side 3M 5423 UHMW Film Tape for Spray Booth Liners
3M 5423 is a double-sided transparent UHMW tape with a abrasion resistant backing that protects the surface from wear. 3M UHMW PE Film Tape 5423 is a thick caliper universal polyethylene tape that produces a “sliding surface” effect, making contact fray-free while reducing the squeaking caused by movement, ideal for the use because of contamination and non-lubricated applications. The effectiveness of 3M 5421 UHMW-PE film tape mainly lies in its Ultra-High Molecular Weight Polyethylene (UHMW-PE) backing, and UHMW-PE is a thermoplastic that has a unique combination of properties, such as exceptional hardness and low surface energy. 3M UHMW-PE Film Tape 5423 is a thicker version of 3M UHMW-PE Film Tape 5421.
-
High Adhesion 3M 9471LE 300LSE Adhesive Transfer Tape for Components Assemble
3M 9471LE, double coated with 300LSE2 mil (0.05 mm) acrylic adhesive, is a versatile, market proven transfer tape on a release liner. The transfer adhesive tape is usually for indoor and outdoor use that features high viscosity and high adhesion, making it suitable for bonding on different substrates. 3M 9471LE adhesive provides excellent retention and resistance to lift and fall, making it the ideal solution for general purpose accessories and components in a variety of materials. It also has good resistance to industrial chemicals, consumer chemicals, moisture and humidity, meeting a wide variety of automotive and OEM specifications.
-
3M 4229P Dark Gray Acrylic Foam Tape for Automotive Exterior Attachment
3M 4229P Acrylic Foam Tape, also named automotive foam tape, is a medium-density, dark gray acrylic foam tape with high performance acrylic adhesives. 3M acrylic foam tape 4229P is characterized by high performance peel and shear adhesion, high internal strength, good conformability and excellent plasticizer resistance.
It features two adhesives, one on each side of a 0.76 mm acrylic foam core, designed for robust performance and shear strength on automotive surfaces such as clear coats. The liner side adhesive is formulated for high initial and final adhesion to rigid clear coat systems. The non liner-side adhesive works on plastics and other common trim materials.
This tape is designed for attaching a range of trim and components to clear coat systems. It is well used on all parts, especially plastics such as RIM, TPO, PPO, PP and PC.
-
Excellent Chemical Resistance 3M 9485PC Adhesive Transfer Tape for Bonding Foams to LES materials
3M 9485PC is a double-sided transfer tape suitable for indoor and outdoor use, and leverages the power of 3M High Performance Acrylic Adhesive 350. 3M 9485 has 3M 9485PC and 3M 9485EK. PC refers to the release Paper as Polycoated Kraft Paper, and EK refers to Extensible Polycoated Kraft Paper for release paper color white. 3M 5952 has very good performance for chemical resistance and shear and peel strength even at elevated temperatures. It can be applied to short term temperature exposure up to 450°F (232°C) and long term 300°F (149°C).5.0 mils (.127 mm) thick tape provides high bond to low surface energy substrates and powder coated paints. It is a fiber reinforced adhesive, a feature that is important for roll stability in narrow widths. This tape is ideal for joining materials that have rougher surfaces.
-
High Abrasion Resistant 3M 5421 UHMW Film Tape for Surfaces Protecting
The 3M UHMW 5421 polyethylene tape is used to protect the surface from abrasion and is a thin universal polyethylene caliper tape that creates a “slipping surface” effect so that contact surface doesn’t get worn out. The effectiveness of 3M 5421 UHMW-PE film tape mainly lies in its Ultra-High Molecular Weight Polyethylene (UHMW-PE) backing, which significantly reduces friction to create an effective solution for anti-stick and easy-release requirements. The tape has a unique combination of properties that makes it ideal for many heavy impact or sliding applications. 3M UHMW-PE Film Tape 5421 is a thinner version of 3M UHMW-PE Film Tape 5423.
