IP68 Waterproof ePTFE Vent Membrane for Automotive Headlight and Taillight

Short Description:

Expanded Polytetrafluoroethylene (ePTFE) vent membrane is a microporous high-performance material produced by stretching PTFE, featuring high strength, breathability, waterproofing, chemical inertness and light weight. It is ultra-thin, typically 0.01–0.2mm, with high porosity. It can be laminated with PET non-woven fabric, polyester fabric, nylon, PP mesh and other materials for varied thickness. Coated with 3M 300LSE and 9495LSE adhesive, it becomes easy-to-install and offers waterproof, oleophobic, dust-proof, temperature-resistant (-200℃ to 260℃) and corrosion-resistant performance. It is widely used in chemical and pharmaceutical precision filtration, oil-water separation, breathable medical dressings, artificial pouches, lithium battery ventilation components, electronic waterproof breathers, as well as outdoor fabrics like jackets, footwear and tents.

Send email to us

Product Detail

Product Tags

IP68 Waterproof ePTFE Vent Membrane for Automotive Headlight and Taillight

GBS® Vents work to protect the enclosure by enabling bidirectional airflow while resisting liquid and particles from entering.

Features

(1) High air flows

(2) IP rating up to IP68

(3) High-efficiency particulate filtration

(4) Balance the pressure difference between the inside and outside

(5) Hydrophobic and Oleophobic to prevent liquids and particle from entering

(6) Easy to install, supporting manual and automated assembly

(7) Standard and custom sizes and shapes are available, with weld and adhesive options

Product number	Color	Thickness,mm	Typical Air Permeability,ml/cm2/min@7kPA	WEP, KPa	IP Rating	Characteristic	Temperature range
VM-W Series	White	0.2	200	100	IP67,IP68	Hydrophobic	-40°C~150°C
		0.2	600	85	IP67,IP68	Hydrophobic/Oleophobic	-40°C~120°C
		0.2	1500	25	IP67	Hydrophobic/Oleophobic	-40°C~120°C
		0.2	3000	10	IP65	Hydrophobic	-40°C~100°C
VM-B Series	Black	0.2	300	90	IP67,IP68	Hydrophobic	-40°C~150°C
		0.2	800	75	IP67,IP68	Hydrophobic/Oleophobic	-40°C~120°C

Using proprietary technology, the membrane’s microporous structure can be tailored to varied application needs.

Application:

Our high-performance vent membrane delivers reliable pressure equalization, waterproofing, dust resistance and breathable protection across automotive lighting, outdoor products, solution packaging, sensors, plant cultivation, electric toothbrushes, automotive & EV battery packs, PCB and electronic assemblies; it effectively mitigates condensation, relieves pressure fluctuations caused by temperature or altitude changes, blocks liquids, dust and contaminants, improves stability, safety and service life, and features high breathability, waterproof/dustproof performance and excellent chemical/UV resistance to adapt to diverse assembly processes and upgrade reliability and lifespan for precision devices and industrial systems. Our products are equivalent to Gore’s vent membranes and offered at competitive price,contact us to get free sample for testing!

Served Industries:

Automotive Industry: Headlights, ECUs, fluid reservoirs, motors, new energy battery packs

Electronics & Telecommunications: Consumer electronics housings, outdoor sensors, base station equipment, junction boxes, outdoor luminaires

Packaging Industry: feed packaging，Pesticide packaging (plant growth media, probiotics, compost, pesticides
