Double Side Kapton Tape for Electronic Component Manufacturing
Double side polyimide kape tape use polyimide film as carrier with double side silicone adhesive coated. It can be widely used in the manufacturing of electronic industry, automotive industry, SMT Surface fixing, lithium battery processing.
Thickness is available from 50um-175um as per client’s requirement.
General size is 500mm width and 33meters length.
Besides of that, Single Side Kapton Tape and Kapton Film with No Adhesive is available.
-
High Heat Kapton Poylimide Tape for PCB Processing
GBS Kapton polyimide tape uses polyimide film as substrate coated with single side or double side high performance organic silicone adhesive. Capable of wide temperature range from -260°(-452°F ) to 260°(500°F), such high heat polyimide tape can be used in high temperature working temperature on printed circuit boards during wave solder or reflow soldering, SMT surface mounting, Transformer manufacturing, as well as lithium battery positive and negative and ears fixed. It has been widely used in Aerospace, aviation, marine, spacecraft, missile, rockets, atomic energy, electrical and electronic industry and other fields.
Color options: Amber, Black Red
Polyimide film thickness options: 12.5um, 25um, 35um, 50um, 75um. 100um, 125um.
Available roll size:
Max width: 500mm(19.68inches)
Length: 33meters
-
High temperature Polyester Tape for Powder Coating Masking
GBS high temperature polyester tape, also named green masking tape, uses polyester film as carrier backing and coated with high performance silicone pressure sensitive adhesive. With high temperature resistance features, PET Polyester tape is suitable to apply on electronic assembly masking and powder coating masking.
Color options: Green, Transparent, Blue
Film thickness options: 60um, 80um, 90um
-
Heat Sealing Skived PTFE Film Tape for Wire Bundling and Harnessing
Skived PTFE film tape uses an extruded polytetrafluoroethylene (PTFE) film as backing coated with pressure sensitive silicone adhesive. PTFE Film tape offers an excellent low friction, chemical resistant, heat resistant, smooth and non-stick surface property in many type of industry applications.
Thickness options: 50um, 80um , 130um, 180um
-
Glass Cloth PTFE Teflon Adhesive Tape for High Temperature Bundling
GBS PTFE Teflon adhesive tape uses high tensile strength glass cloth combined with PTFE film as backing material coated with high performance pressure sensitive silicone adhesive. Comparing with pure PTFE Film tape, glass cloth reinforces the tensile strength and tear resistance which provides more durable solution on packaging and heat sealing machines.
Thickness options: 80um , 130um, 180um,300um
