3M 966 Double-sided Adhesive Transfer Tape for Flexible Printed Circuit (FPC)

Short Description:

3M 966 adhesive transfer tape is a transparent, double-sided adhesive transfer film, which is composed of 3M high temperature acrylic adhesive 100 and 62# densified kraft paper release liner. At~2 mil (0.05 mm) thick, delievering a thin, high-strength bonding profile with low outgassing properties that meet NASA low-outgassing specifications (ASTM E 595). Engineered for the demanding needs of the aerospace, automotive, and electronics industries, it provides reliable performance in high-temperature, high-strength, and chemically aggressive environments.

Send email to us

Product Detail

Product Tags

3M 966 Double-sided Adhesive Transfer Tape for Flexible Printed Circuit (FPC)

Features

1. Low-outgassing performance advantages aerospace/automotive/electronics sectors.

2. 2mil (0.05mm) clear double-sided transfer tape combines slim construction with high-temp acrylic adhesive for durable bonding.

3. 62# densified kraft liner minimizes metal plate edge burr during manual tooling.

4. Exceptional peel/shear strength ensures extreme-environment bonding reliability.

5. Superior UV/chemical resistance enhances long-term durability.

6. 450°F (232°C) short-term heat endurance.

Product name	3M 966 Double-sided Adhesive Transfer Tape for Flexible Printed Circuit (FPC)
Backing material	no backing
Adhesive Type	High Temperature Acrylic Adhesive 100
Product Color	Translucent
Maximum Operating Temperature	232℃
Minimum Operating Temperature	-40 ℃
Total Tape Thickness without Liner	0.058mm
Shelf Life	24 months
