  • Lithium Battery Tape

    • GBS ashesive tape
    Battery tape is widely used in various industries for battery protection. As a professional and experienced tape manufacturer, GBS Tape provide lithium battery tapes as well, mainly including battery tab tape, battery exclusive protection tape, static-free protective tape, Silicone polyester tape, termination tape, thermal expension tape, anti-drop tape, formable polyimide tape, etc,.
    • Flame Retardant Polypropylene Material ITW Formex GL-10 and GL-17 for EV Battery Pack

      Flame Retardant Polypropylene Material ITW Formex GL-10 and GL-17 for EV Battery Pack



      Formex GL series is the newest formulation of flame retardant polypropylene electrical insulation material from ITW Formex family. It includes GL-10 and GL-17 with thickness of 0.017 inch and 0.010 inch for chosen. Formex GL series shares the same exceptional reliability and durability as its GK series while offering more enhanced temperature resistance. Formex GL series provides a viable alternative solution to GK when the application require a thinner gauge material that offers superior temperature tolerance. Till now, GL series material has been widely applied on EV industries, like EV Battery Pack, EV power electronic controller, EV DC Charging, etc,. Here at GBS Tape, we’re available to provide GL-10 and GL-17 material in roll size and also provide precision die cut service for clients easy application.





    • Die Cut ITW Formex GK 17 Polypropylene Insulation Paper for Transformers Application

      Die Cut ITW Formex GK 17 Polypropylene Insulation Paper for Transformers Application



      ITW Formex GK 17 is a type of Polypropylene insulation paper with thickness of 0.017in(0.43mm), and roll size with 610mm x 305meter. It belongs to the Formex GK series family, which is flame retardant with UL 94-V0 certificated. GK-17 provides superior electric surge shielding in industrial and consumer electronic equipment. Formex GK series insulation paper also features excellent chemical resistance, low water absorption and high dielectric breakdown voltage, which can replace a variety of electrical papers, thermoplastic materials, and injected molded parts. We can provide jumbo roll size for GK-17 and also slit small size as well as precision die cut into custom shape to apply on different industries, such us Transformer Insulation, LED Lighting industry, and other consumer electronic manufacturing process.





    • Precision Die Cut ITW Formex Insulation Paper GK-5 and GK-10 for Battery Insulation Gasket

      Precision Die Cut ITW Formex Insulation Paper GK-5 and GK-10 for Battery Insulation Gasket



      ITW Formex GK-5(0.005in.) and GK-10(0.01in.) is a type of Polypropylene Formex Insulation paper, which is flame retardant with UL 94-V0 certificated. It provides superior electric surge shielding for industrial and consumer electronic equipment. Formex GK series insulation paper also features good chemical resistance, low water absorption and high dielectric breakdown voltage, which can replace a variety of electrical papers, thermoplastic materials, and injected molded parts. Here at GBS, we can provide GK-5 and GK-10 in rolls as well as precision die cutting into custom shape and size to be applied on different industries, such us battery insulation gasket, LED Lighting industry, Transformer, and some other consumer electronic manufacturing process.





    • Low Adhesion Single Side Polypropylene Film Battery Pack Tape for Lithium Protection

      Low Adhesion Single Side Polypropylene Film Battery Pack Tape for Lithium Protection



      Our Battery pack tape uses special Polypropylene film as carrier then coated with low adhesion acrylic adhesive for lithium battery protection. It features with high temperature resistance to 130℃, and it can be peeled off without residue and pollution to the battery surface. It’s not only used to pack the power battery to provide protection during transportation but also provide protection during the bar code printing on the battery cell.

      Our color is available in blue and transparent, and we can provide both material in rolls and die cutting custom sizes as per client’s application.

    • Low Adhesion Thermal Expansion Lithium Battery Tape for Core&Shell Protection

      Low Adhesion Thermal Expansion Lithium Battery Tape for Core&Shell Protection



      Thermal expansion Lithium Battery Tape uses special resin film as carrier and coated with very low adhesion acrylic adhesive. The tape is very thin and flexible, it’s usually used to fix between the lithium battery cell and shell to provide shock absorption protection for power battery. The tape thickness and volume would be increased after immersed by electrolyte bath, meanwhile, the battery’s volume and internal resistance keep no change. It’s widely used on the process of cylindrical lithium battery to protect and fix the battery core and shell during liquid injection.

    • Polyimide Aerogel Thin Film for Electronic Devices Heat Insulation

      Polyimide Aerogel Thin Film for Electronic Devices Heat Insulation



      Polyimide aerogel film uses polyimide as carrier and specially treated nano aerogel on the polyimide film. Compared with polyester aerogel film, our polyimide aerogel film features higher temperature resistance and electrical insulation, and it can resist to higher temperature around 260℃-300℃, which provides excellent heat insulation function during the processing of manufacturing electronic components.

      Our polyimide aerogel film has very low thermal conductivity and heat insulation features, which can solve the problem of heat equalization of consumer products in a small space, and provide heat insulation protection for the weak heat-resistant components. Besides, it can also control and change the direction of heat conduction to improve performance and shelf life of the products.

    • Strong Adhesion Acrylic Adhesive Polyester EV Battery Tape for Housing Protection

      Strong Adhesion Acrylic Adhesive Polyester EV Battery Tape for Housing Protection



      Our Electric Vehicle(EV) Battery Tape is a type of double layers polyester film tape, which uses two layers of special polyester films as carrier and coated with strong adhesion acrylic adhesive. It features with friction resistance, high insulation and voltage resistance properties, and also very easy to peel off without residue and pollution to battery surface. It’s not only used to pack the power battery to provide protection during transportation but also used as an insulation protection during the processing and assembly of EV power battery.

      Our color is available with blue and black, and we can provide both material in rolls and die cutting custom size according to client’s application.

    • Polyester Termination Film Tape with Solvent Acrylic Adhesive for Lithium Battery Tab Insulation

      Polyester Termination Film Tape with Solvent Acrylic Adhesive for Lithium Battery Tab Insulation



      The Battery Insulation Tape uses polyester termination film as carrier then coated with solvent acrylic adhesive. It provides excellent performance under acid or alkaline condition, and it also resists to the electrolyte. It has moderate peel strength and consistent unwinding force which can be smoothly operated on the automatic production line. The polyester termination film tape is widely used as insulation and protection for the lithium battery or nickel battery, cadmium battery.

    • Polypropylene BOPP Film Tape for Lithium Battery Termination, Insulation and Fixing

      Polypropylene BOPP Film Tape for Lithium Battery Termination, Insulation and Fixing



      BOPP film tape uses flexible polypropylene film as carrier coated with solvent acrylic adhesive. It provides excellent performance under acid or alkaline condition, and it also resists to the electrolyte. It has moderate peel strength and consistent unwinding force which can be smoothly operated on the automatic production line. The polyester termination film tape is widely used as insulation and protection for the lithium battery or nickel battery, cadmium battery.

    • Kapton Acrylic Adhesive Tape for Termination’s Fixing of Lithium battery

      Kapton Acrylic Adhesive Tape for Termination’s Fixing of Lithium battery



      Kapton Acrylic Adhesive Tape uses heat resistance polyimide film as carrier and coated with high performance solvent acrylic adhesive. It provides excellent performance under acid or alkaline condition, and it also resists to the electrolyte. It has moderate peel strength and consistent unwinding force which can be smoothly operated on the automatic production line. The temperature can resist to 160℃, it’s usually used as battery tab tape to provide fixing and packing and insulation for lithium battery or nickel battery, cadmium battery.
