Mica Plates for Thermal Electrical Insulation in Appliances and Power Systems

Short Description:

Muscovite or Phlogopite Mica Plates are premium insulating laminates consisting of approximately 90% natural mica paper and about 10% high-temperature silicone resin, hot-pressed into rigid or flexible sheets. These mica plates provide exceptional electrical insulation and dielectric strength, along with excellent thermal resistance ranging from 500℃ to 1000℃, while maintaining mechanical strength and dimensional stability under thermal cycling or mechanical stress. The material also features low thermal conductivity, outstanding flame resistance, and stable chemical properties. It can be precisely machined into custom components such as gaskets, washers, heater-element supports, slot wedges, insulating spacers, and other structural insulation parts. Available in a wide range of thicknesses (from 0.1 mm to over 50 mm) and fully customizable in size, these mica plates are widely used in electric motor and generator insulation, transformers, high-voltage switchgear, household and industrial heating appliances, furnaces and metallurgical equipment, high-temperature sealing and gasket systems, and various thermal barrier or fire-resistant applications.

Send email to us

Product Detail

Product Tags

Mica Plates for Thermal Electrical Insulation in Appliances and Power Systems

Features

1. Excellent insulating properties at high temperature: At 500-1000℃ operating ambient temperature, the voltage breakdown resistance is 15kV/mm.

2. Low thermal conductivity for effective heat shielding.

3. High mechanical strength with good resistance to thermal shock.

4. Flame-resistant, non-combustible, and emits no toxic smoke.

5. Stable chemical and moisture resistance for harsh environments.

6. Easy to machine: can be cut, drilled, punched, or CNC-processed.

7. Available in rigid or flexible grades with thicknesses from 0.1 mm to over 50 mm.

8. Customizable sizes and shapes for advanced insulation components.

9. Customizeble die cutting service for advanced

Application:

Mica plates are widely used across the electrical and power industry, household appliance manufacturing, industrial heating systems, metallurgy and thermal processing, machinery and equipment production, power distribution and control systems, as well as fire protection and safety applications. They serve as high-temperature insulation, thermal barriers, and structural support materials, ensuring reliable thermal, electrical, and mechanical protection in demanding environments.

Served Industries:

(1) Electrical and Power Industry: Insulation and thermal barriers for motors, generators, transformers, and high-voltage switchgear.

(2) Household and Commercial Appliances: Insulation support for heating elements in irons, ovens, hair dryers, coffee machines, and warming devices.

(3) Industrial Heating and Thermal Processing: Structural insulation for industrial heaters, heating coils, cartridge heaters, and mold-heating systems.

(4) Metallurgy and High-Temperature Processing: Thermal insulation and structural support for furnaces, kilns, casting equipment, and metal heat-treatment systems.

(5) Machinery and Industrial Sealing: High-temperature gaskets, washers, spacers, and sealing components in industrial equipment.

(6) Power Distribution and Control Systems: Arc-resistant insulation parts, electrical isolation components, and high-voltage insulating hardware.

(7) Fire Protection and Safety Systems: Fire-resistant boards, thermal shields, and protective barriers for high-temperature safety applications.
